规格
| System | |
| Processor | 6th Gen Intel® Core™ i5-6300U, 2-Core, 2.4GHz processor |
| System Memory | 2 x 260-Pin DDR4 2133MHz SO-DIMM |
| I / O Chip | EC ITE IT8528E |
| Watchdog Timer | H/W Reset, 1sec. ~ 65535sec./1sec.step |
| H/ W Status Monitor | H/W Reset, 1sec. ~ 65535min. and 1sec. or 1min./step |
SBC | EBM-SKLU |
| Expansion | 1 x Mini PCIe Support mSATA 1 x Mini PCIe Supports SIM Card |
| Storage | 1 x 2.5" Drive Bay |
| I /O | |
| USB | 4 x USB 3.0 |
| SATA | 1 x SATA III |
| COM Port | 2 x RS-232/422/485 (Factory Optional) |
| Other | 1 x HDMI Output 1 x Knockouts for Antenna Mounting |
| Display | |
| Chipset | Intel® Skylake SoC integrated Graphics Supports dual display |
| Resolution | HDMI: Max. resolution 4096x2160 @ 24Hz |
| Audio | |
| Chipset | Realtek ALC892 |
| Audio Interface | Line-Out |
| Ethernet | |
| Chipset | 1 x Intel® I210AT 1 x Intel® I219LM |
Ethernet Interface | 10/100/1000 Base-Tx GbE compatible |
| LAN Port | 2 x RJ-45 |
| Mechanical & Environmental | |
| Operating Temp | -10°C ~ 50°C (14°F ~ 122°F) |
| Storage Temp | -20°C ~ 60°C (-4°F ~ 140°F) |
Operating Humidity | 0% ~ 90% Relative Humidity , Non -Condensing |
Weight | 2.84 Kgs |
| Dimension ( L x W x H) | 283 x 222 x 45 mm |
| Certifications | |
| Certification Information | CE / FCC Class B |
| Software Support | |
| OS Information | Win 7 / Win 8 / Linux |
| Power Requirement | |
| Power Requirement | +12V ~ +26V |
| Power Mode | AT/ATX (ATX is default setting) |
| Panel | |
| LCD Size | 12.1", 4:3 |
| Display Type | XGA |
| Resolution | 1024x768 |
| Pixel pitch | 0.240mm(H) x 0.240mm(V) |
| Luminance | 600 cd/m2 |
| Contrast ratio | 700 |
| Viewing angle | 70 (U), 70 (D), 80 (L), 80 (R) |
| Response time | 16 ms |
| Backlight | LED |
| Touch Type | 5 Wires resistive |
| Touch Light Transmission | 80% |
| Touch Controller | Onboard USB touch (EETI) |
