| Specifications | |||
| Processor & System | |||
| CPU | Quad-core Intel® Core™-i7-3612QE 2.1GHz, 6MB LLC cach e, 35W TDP | ||
| Chipset | Mobile Intel® QM77 Express Chipset | ||
| Memory | Dual channel DDR3-1333 ECC soldered SDRAM, up to 8GB | ||
| BIOS | AMI EFI on 64Mbit SPI flash | ||
VITA Standards | VITA 46.0 VPX Base Standard VITA 46.4 PCI Express on VPX Fabric Connector VITA 46.6 Gigabit Ethernet Control Plane on VPX VITA 46.9 PMC/XMC/Rear IO Fabric Signal Mapping to 3U/ 6U VPX VITA 48.0 Ruggedized Enhanced Design Implementation Me chanical Base Specification VITA 65 OpenVPX Architecture Framework for VPX | ||
| Module Profile | MOD3-PAY-2F2T-16.2.5-3 MOD3-PAY-2F2U-16.2.3-3 (BOM Option) | ||
| Slot Profile | SLT3-PAY-2F2T-14.2.5 SLT3-PAY-2F2U-14.2.3 (BOM Option) | ||
Connectivity | |||
| XMC | PCIe x8 Gen2 with RIO to P2-X8d+X12d | ||
Ethernet | Two 1000BASE-T to P1 Two 1000BASE-BX to P1 (BOM Option) | ||
| Graphics | Intel® HD Graphics 4000 One VGA to P2 | ||
| USB | Two USB 2.0 to P1 | ||
| Serial Port | Two RS-232/422 to P1 One RS-232/422 to P2 | ||
| PCI Express | 2x PCIe x4 Gen2 to P1, configurable to 1x8 or 1x4+4x1 Supports DMA and Non Transparent Bridge for peer to pe er communication | ||
| Storage | |||
| SBC | Soldered 32GB SATA 3Gb/s boot flash One SATA 6Gb/s ports to P1 | ||
| Operating System | |||
| OS | Red Hat Enterprise Linux 6.2 Wind River VxWorks 6.9 Microsoft Windows 7 32/64bit Microsoft Windows 7 Embedded | ||
