| Specifications | ||
| Model Name | MXE-1501 | MXE-1502 |
| System Core | ||
| Processor | Quad Core Atom N3160 1.6GHz, up to 2.24GHz | Dual Core Atom N3060 1.6GHz, up to 2.48GHz |
| Memory | DDR3L soldered 2G/4G + 2G/4G SODIMM | |
| Graphic Output | ||
| Display Port | 1x DisplayPort | |
| DVI / VGA | 1x VGA | |
| LVDS | 18/24bit single-ch LVDS (optional) | |
| I/O Interface | ||
| Ethernet | 3x GbE (Intel® I211) | |
| Serial | 2x RS-232/422/485 + 2x RS-232 2x RS-232/422/485 (optional) | |
| USB | 4x USB3.0 + 2x USB2.0 + 1x internal USB2.0(dongle) | |
| Audio | Mic-in / Line-out amplifier (optional) | |
| DI/O | 4DI + 4DO | |
| Expansion | ||
| Mini PCIe | 1x full size Mini PCIe | |
| USIM | 1x USIM | |
| Manageability | ||
| WDT | Watch Dog Timer supported by SEMA | |
| SEMA | SEMA 3.5 | |
| Power Supply | ||
| DC Input | 6-36VDC | |
| AC Input | Optional 90 W AC/DC adapter | |
| Storage Device | ||
| SATA Storage | 1x 2.5" SATA | |
| CompactFlash | 1x CFast | |
| Mechanical | ||
| Dimensions | 210 (W) x 170 (D) x 53 (H) mm | |
| Weight | - | |
| Mounting | Wall mount DIN rail (optional) | |
| Environmental | ||
Operating Temperature* | Standard: 0°C to 50°C (32°F to 122°F) Extended temperature option*: -20°C~70°C (-40°F to 158°F) (w/ industrial SSD and air flow) | |
Storage Temperature | -40°C to 85°C (-40°F to 185°F) | |
| Humidity | Approx. 95% @40°C (non-condensing) | |
| Vibration | Operating 5Grms, 5-500 Hz, 3 axes w/ SSD; Operating 0.5Grms, 5-500 Hz, 3 axes w/ HDD | |
| ESD | Contact +/- 6KV, Air +/- 10KV | |
| EMC | CE & FCC Class A | |
| Shock | Operating 100G, half sine 11 ms duration w/ SDD;Operating 20G, hafl sine 11ms w/ HDD | |
| Safety | UL[by CB] | |
