Focus on technical applications such as motion control data acquisition and br equipment IoT
规格
| System | |
| Processor | Intel ® Atom™ x 5-Z8350: 2M Cache, up to 1. 92 GHz |
| System Memory | 2GB DDR3L RAM |
| Other | 802. 11 b/ g/ n Wi Fi |
| Storage | 32GB eMMC |
| I /O | |
| External I / O Connector | 1 x RJ45 for RS232 or RS422 or RS485 2 x USB 2. 0 Type A 1 x 10/ 100/ 1000 Ethernet 1 x 4-Pin 3. 5mm Audio Jack |
| Internal I / O Connector | 1 x Touch Button interface 1 x eDP & Dual channel 24bi t LVDS 1 x I2C interface for PCAP 5 x USB interface for PCAP, Camera and others 1 x MicroUSB2. 0 client (reserved) 1 x MicroSD conn ector 2 x LED Bar interface |
| Camera | 2. 0MP Camera |
| Dispaly | |
| Multiple Display | Windows support extended mode |
| Mechanical & Environmental | |
| Power Requirement | DC Inpu t , 12~24V |
| Power Type | DC jack or Power over Ethernet (PoE) 802. 3AT |
| Operating Temp | 0°C ~ 40°C |
| Storage Temp | -10°C ~ 60°C (14°F ~ 140°F) |
Operating Humidity | 0% ~ 90% Relative Humidity , Non -Condensing |
| Software Support | |
| OS Information | Windows 10 IoT (64 bit ), Android 5. 1(64 bit ) |
| Panel | |
| LCD Size | 10. 1" |
| Resolution | 1280x 800 |
| Luminance | 350 |
| Contrast ratio | 700~ 1000 |
| Viewing angle | 170° (H/ V) |
| Touch Type | PCAP |
| Data Col lection | |
| NFC | NFC Reader |
