规格
| System | |
| Processor | Intel ® Core™ i7/ i5/ i3 Processor Celeron Series |
| System Chipset | Intel ® QM67 Express Chipset |
| System Memory | 2 x 204-Pin up to 4GB |
| I / O Chip | Nuvoton NT C6776F |
| Watchdog Timer | H/W Reset , 1sec. ~ 65535min . |
| H/ W Status Monitor | Monitoring CPU & System Temperature and Voltage |
| SBC | AID-173SHR |
| Expansion | 3 x Mini PCIe |
| Storage | 1 x 2. 5" Drive Bay |
| I /O | |
| USB | 4 x USB 2. 0 |
| COM Port | 1 x RS-232 1 x RS-232/ 422/ 485 |
| Other | 1 x HDMI Ou t pu t 1 x Di spl ay Ou t pu t 1 x Earph on e 1 x Mi c |
| Display | |
| Chipset | Intel ® QM67 Chipset Integrated Supports dual display |
| Resolution | DP:Max . resolution 2560x 1600 HDMI :Max . resolution 1920x 1080 |
| Audio | |
| Chipset | Realtek ALC892 |
| Audio Interface | Mic-In and Line-Out |
| Audio Amplifier | Anpec APA4863RI -TRG |
| Speaker Output | 2 x 2W |
| Ethernet | |
| Chipset | 1 x Intel ® 82579LM |
Ethernet Interface | 10/100/1000 Base-Tx GbE compatible |
| LAN Port | 2 x RJ-45 1 x RJ-45 |
| Mechanical & Environmental | |
| Operating Temp | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temp | -20 ~ 65°C (-4 ~ 149°F) |
Operating Humidity | 20% ~ 80% |
Weight | 4. 7Kgs |
| Dimension ( L x W x H) | 505 x 336 x 54. 5mm |
| IP Rating | Front IP65 |
Vibration Test Shock Test | With SSD/mSATA : 1. 5Grms, I EC 60068-2-64, Random, 5 ~ 500Hz , 30min / axis With CF/ SSD : 10Grms, IEC 60068-2-27, Half Sine, 11ms |
| System Fan | Fanless |
| Construction - Front | White Plastic |
| Construction - Rear | White Plastic |
| Finishing | Anti -microbial |
| Certifications | |
| Certification Information | CE FCC Cl ass B UL |
| Software Support | |
| OS Information | Win XP Win 7 Win 8 Linux |
| Power Requirement | |
| Power Connector | DC Jack |
| Power Requirement | +12V ~ +19V |
| Power Mode | AT / ATX (ATX is default setting) |
| Battery | 1100mAh 4S1P (by optional ) |
| Battery Operating Time | max . 20 mins backup operation |
| Adapter | Input : 100 ~ 240 Vac / 50~ 60Hz ; Output 65W Adapter (19V / 3. 43A Adapter) |
| Panel | |
| LCD Size | 17. 3" |
| Display Type | Full HD |
| Resolution | 1920 x 1080 |
| Pixel pitch | 0. 1989 (H) x 0. 1989 (V) mm |
| Luminance | 300 cd/m² |
| Contrast ratio | 500~650 |
| Viewing angle | Horizontal 60-70; Vertical 50-60 Deg. |
| Response time | TR 2-8 ms; TF 6-12 ms |
| Backlight | LED |
| Touch Type | 5 Wires resistive |
| Touch Light Transmission | 80% +/ - 3% |
| Touch Controller | On board USB touch (EETI ) |
