Focus on technical applications such as motion control data acquisition and br equipment IoT
规格
| System | |
| Processor | Intel® Atom™ Processor Z3735F 1.33GHz Quad Core CPU |
| System Chipset | 2GB DDR3L RAM |
| Storage | |
| Storage | 8GB or 32GB eMMC |
| I/O | |
| External I/O Connector | 2 x USB 2.0 |
| Internal I/O Connector | 1 x 16 bit GPIO interface 2 x USB interface 2 x speaker interface (1.2W stereo) 1 x A-MIC interface 1 x Touch Button connector 1 x DC input 4pin header 1 x I2C interface(optional) |
| Display | |
| Multiple Display | Windows/ Linux support extended mode; Android support clone mode only |
| Mechanical & Environmental | |
| Power Requirement | DC 12~24V Input |
| Power Type | DC Jack, DC input 4pin header |
| Operating Temp | 0°C ~ 40°C |
| Storage Temp | -10°C ~ 60°C |
| Operating Humidity | 0% ~ 90% Relative Humidity, Non-condensing |
| Weight | 0.33kg |
| Dimension (L x W x H) | 116 x 184 x 25mm |
| Software Support | |
| OS Information | Windows 10(32 bit)/ Android 4.4(64 bit)/ Ubuntu 14.04(64 bit) |
| Power Requirement | |
| Battery | Li-ion rechargeable battery 2400 mAh(Optional, P/N:ACC-BAT-3S1P-01R) |
| Panel | |
| LCD Size | 7" |
| Display Type | LED |
| Resolution | 1280x800 |
| Luminance | 300 |
| Touch Type | PCAP |
| Wireless Communication | |
| WLAN | 802.11 b/g/n |
| Bluetooth | 4.0 |
