Product
Focus on technical applications such as motion control data acquisition and br equipment IoT
规格
| System | |
| Processor | Intel® Atom™ x5-Z8300/Z8350 Processor: 1.44GHz |
| System Chipset | 2GB DDR3L RAM |
| Other | 802.11 b/g/n WiFi |
| Storage | |
| Storage | 32GB eMMC |
| I/O | |
| External I/O Connector | 2 x USB 2.0 |
| Internal I/O Connector | 1 x RS232(TX/RX) or RS485 1 x 16 bit GPIO interface 1 x USB interface 1 x eDP & Dual channel 24bit LVDS 1 x backlight control & power 2 x speaker interface (1.2W stereo) 1 x A-MIC interface 1 x Touch Button connector 1 x DC input 4pin header 1 x I2C interface(optional |
| Display | |
| Multiple Display | Windows support extended mode and clone mode |
| Mechanical & Environmental | |
| Power Requirement | DC 12~24V Input |
| Power Type | DC Jack, DC input 4pin header, optional Power Over Ethernet 802.3AT |
| Operating Temp | 0°C ~ 40°C |
| Storage Temp | -10°C ~ 60°C |
| Operating Humidity | 0% ~ 90% Relative Humidity, Non-condensing |
| Weight | 1.18kg |
| Dimension (L x W x H) | 252 x 166 x 38 mm |
| Software Support | |
| OS Information | Windows 10 IoT (64 bit) |
| Panel | |
| LCD Size | 10.1" |
| Resolution | 1280x800 |
| Luminance | 350 |
| Viewing angle | 170° (H/V) |
| Touch Type | PCAP |
