Product
Focus on technical applications such as motion control data acquisition and br equipment IoT
规格
| System | |
| Processor | Intel® Atom™ Processor Z3735F 1.33GHz Quad Core CPU |
| System Chipset | 2GB DDR3L RAM |
| Storage | |
| Storage | 32GB eMMC |
| I/O | |
| External I/O Connector | 2 x USB 2.0 1 x micro USB Client(Android only) 1 x 10/100 Ethernet 1 x HDMI |
| Internal I/O Connector | 1 x USB interface |
| Mechanical & Environmental | |
| Power Requirement | 19V DC input |
| Power Type | DC Jack |
| Operating Temp | 0°C ~ 40°C |
| Storage Temp | -10°C ~ 60°C |
| Operating Humidity | 0% ~ 90% Relative Humidity, Non-condensing |
| Weight | 8.1 kg with packing material |
| Software Support | |
| OS Information | Android 4.4.4 (64 bit) |
| Power Requirement | |
| Battery | Li-ion rechargeable battery 2400 mAh(Optional, P/N:ACC-BAT-3S1P-01R) |
| Panel | |
| LCD Size | 15.6" |
| Resolution | 1920x1080 |
| Luminance | 220 |
| Viewing angle | 45°(H+)/ 45°(H-)/ 20°(V+)/ 45°(V-) |
| Touch Type | PCAP |
| Specification | |
| Dimension | Outer Carton 360*270*580mm |
