Focus on technical applications such as motion control data acquisition and br equipment IoT
| systemSystem | |
| Processor | Intel® Celeron® J1900 4-Core 2.0GHz processor |
| System Memory | 1 x 204-Pin DDR3L 1333MHz SO-DIMM up to 8 GB |
| I/O Chip | EC ITE IT8528E |
| Watchdog Timer | H/W Reset, 1sec. ~ 65535sec./1sec.step |
| H/W Status Monitor | Monitoring CPU & System Temperature and Voltage |
| SBC | ARC-BYT |
| Expansion | |
| Expansion | 1 x Mini PCIe Support mSATA 1 x 80-pin IET interface |
| Storage | |
| Storage | 1 x 2.5" Drive Bay (7mm HDD Restricted) |
| I/O | |
| USB | 1 x USB 3.0 3 x USB 2.0 |
| SATA | 1 x SATA II |
| COM Port | 1 x RS-232/422/485 1 x RS-232 |
| Other | 3 x Knockouts for Antenna Mounting |
| Display | |
| Chipset | Intel® Valleyview SoC integrated Graphics Supports optional dual display |
| Resolution | HDMI: Max. resolution 1920x1200 @ 60Hz (optional by IET module) |
| Audio | |
| Chipset | Realtek ALC892 |
| Speaker Output | 2 x 0.6W |
| Ethernet | |
| Chipset | 2 x Intel® I211AT |
| Ethernet Interface | 10/100/1000 Base-Tx GbE compatible |
| LAN Port | 2 x RJ-45 |
| Mechanical & Environmental | |
| Power Type | AT/ATX (ATX is default setting) |
| Operating Temp | -10°C ~ 50°C (-14°F ~ 122°F) |
| Storage Temp | -20°C ~ 60°C (-4°F ~ 140°F) |
| Operating Humidity | 0% ~ 90% Relative Humidity, Non-condensing |
| Weight | 2.5 Kgs |
| Mounting Kit | Wall / Stand / VESA 75mm x 75mm, 100mm x 100mm |
| IP Rating | Front IP65 Rear IP41 |
| Vibration Test | With SSD/mSATA : 3Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis |
| Shock Test | Operating with SSD/CFast/mSATA : MIL-STD-810G, Method 516.6, Procedure I, functional shock=20G |
| System Fan | Fanless |
| Construction - Front | Metal with Cover lens |
| Construction - Rear | Black Diet Casting |
| Certifications | |
| Certification Information | CE FCC Class B |
| Software Support | |
| OS Information | Win 7/ 8.1 / 10 / Linux |
| Ordering Information | |
| Ordering Information | ARC-1209-190-B1-1R Intel Celeron® J1900 4-Core 2.0GHz/2GLAN/2COM/4USB/12V Adaptor Barebone Panel PC Optional IET Module list: ACC-ARC-USB-1R 4 x USB 3.0 Kit for ARC Series ACC-ARC-AUDIO-1R HDMI + 5.1 CH Audio Kit for ARC Series ACC-ARC-MPCIE-1R HDMI + MPCIE w/SIM Kit for ARC Series ACC-ARC-COM-1R 2 x Isolated RS-232 Kit for ARC Series ACC-ARC-COM-2R 3 x RS-232 Kit for ARC Series ACC-ARC-COM-3R 2 x RS-232 + USB Kit for ARC Series ACC-ARC-COM-4R 2 x RS-232 + LAN Kit for ARC Series ACC-ARC-GPIO-1R 12-bit GPIO + 2-pin CAN Bus Kit for ARC Series ACC-ARC-OBDII-1R OBDII - CAN Bus Kit for ARC Series (OBDII/EOBD for Small Vehicle) ACC-ARC-OBDII-2R OBDII - CAN Bus Kit for ARC Series (J1939J1708 for Large Vehicle) ACC-ARC-OBDII-3R OBDII - CAN Bus Kit for ARC Series (ISO15765-4 for Special Large Vehicle) |
| Power Requirement | |
| Power Connector | Lockable DC Jack |
| Power Requirement | +12V ~ +26V |
| Adapter | Input: 100 ~ 240Vac/ 50 ~ 60Hz Output: 60W Adapter (12V @ 5A Adapter) AC-DC Adapter |
| Panel | |
| LCD Size | 12.1", 4:3 |
| Display Type | XGA |
| Resolution | 1024x768 |
| Pixel pitch | 0.240mm(H) x 0.240mm(V) |
| Luminance | 600 cd/m² |
| Contrast ratio | 700 |
| Viewing angle | 80 (U), 80 (D), 80 (L), 80 (R) |
| Response time | 16 ms |
| Backlight | LED |
| Touch Type | Projective Capacitive Multi-Touch up to 10 points |
| Touch Light Transmission | 89 % |
| Touch Controller | USB touch (EETI) |
| Specification | |
| Dimension | 292.86 x 225.4 x 51.5 mm |
