Product
Focus on technical applications such as motion control data acquisition and br equipment IoT
规格
| System | |
| Processor | Intel Atom® x5-Z8350 Processor 2M Cache, up to 1.92 GHz |
| System Memory | 2GB DDR3L RAM |
| Others | 802.11 b/g/n WiFi |
| Storage | 32GB eMMC |
| I /O | |
| External I/O Connector | 1 x DC jack 1 x Micro USB Client(Android only) 1 x Micro SD slot 1 x HDMI 1 x LAN for 10/100/1000 Ethernet 1 x DB9 for COM 1 x USB 2.0 |
| Internal I/O Connector | 1x IET interface 1x Mini PCIE interface 1x SIM 1x COM interface for RS232 1x USB 2.0 interface 1x Touch Button interface 1x backlight control & power 1x I2C interface for PCAP 1x Audio interface(Earphone+Microphone) 1x Speaker interface |
| Display | |
| Multiple Display | Windows support extended mode and clone mode |
| Mechanical & Environmental | |
| Power Requirement | DC input 12 ~ 24V |
| Power Type | DC Jack |
| Operating Temp | 0°C ~ 40°C |
| Storage Temp | -10°C ~ 60°C |
Operating Humidity | 0% ~ 90% Relative Humidity , Non -Condensing |
| Software Support | |
| OS Information | Windows 10 IoT (32 bit) |
| Panel | |
| LCD Size | 15" |
| Display Type | XGA |
| Resolution | 1024x768 |
| Luminance | Typ 250 cd/m2 ,Min 200 cd/m2 |
| Contrast ratio | Typ 700 ,Min 450 |
| Viewing angle | 160°(H), 140°(V) |
| Touch Type | PCAP |
| Touch Controller | USB |
