Product
Focus on technical applications such as motion control data acquisition and br equipment IoT
| Specifications | |||
| Controller | Dual-port Intel® 10Gigabit Ethernet Controller X5 40, 1 0W TDP @ 110˚C, Tj,Max 10G/1G/100Mbps copper PHYs integrated on-chip Jumbo frames up to 15.5KB TCP/UDP segmentation, IPv6 IP/TCP, IP/UDP receive chec ksum offload FCoE Tx/Rx CRC offload, 256KB FCoE transmit segme ntati on | ||
| Host Interface | PCI Express v2.1 (5GT/s) PCI Express X1, x2, x4, x8 lanes Message Signaled Interrupts (MSI/MSI-X) | ||
| Connectivity | Dual RJ-45 ports | ||
Operating System | Windows 7, Server 2003, Server 2008 Red Hat Enterprise Linux 6 | ||
| Mechanical and Environmental | |||
| Form Factor | VITA 42.3 XMC standard with XMC.3 connector 139mm x 74mm x 8.2mm | ||
| Operating Temp | 0°C to 60°C | ||
| Storage Temp | -40°C to 85°C | ||
| Rel. Humidity | 95% (non-condensing) | ||
| Shock | 20G peak-to-peak, 11ms duration, operating | ||
| Vibration | 2Grms, 5-500Hz, each axis, operating | ||
| Power Consumption | Maximum 1.5A@5V 8.5W | ||
